Printdate 118i

Printdate 118i

Upgrading the traditional hot stamping coder, without pre-heating and manually changing types.
The HMI supports hot swap; multi-printers can be connected with one HMI.
Character size is adjustable within print area min. gap between prints 0.5 mm cost saving on consumables.

Model	PD118i
Printhead	24 mm, 200 dpi / 32 mm, 200 dpi
Print Area	24 mm × 15 mm / 32 mm × 15 mm
Pause Time Between Prints	≥ 70 m
Print Frequency	Max. 200 times/min; 20 m/min
Length of Ribbon	350 m
Width of Ribbon	25 mm / 33 mm
Print Features	Time, date, variables, text, etc.
Operation	Multiple machines can share a common operating screen and support hot-swapping; Can be integrated into packaging machines
Communication	USB, RS485
Power Supply	AC90–264 V, 2 A, 50/60 Hz
Power (Output)	48 W
Environmental Requirements	Temperature: 0–40°C; Humidity: 10%–90%, non-condensing
Compressed Air Requirements	No
Weight	Printer Unit: 2.1 kg; Controller: 0.48 kg
Dimensions	Printer Unit: 158 × 149 × 114 mm; Controller: 210 × 135 × 36 mm
